KEY FACTS

  • Frequency Range: 9 kHz To 6.3/8.5 GHz
  • 1 GHz DANL: -166 dBm/Hz
  • 1 GHz Phase Noise: -110 dBc/Hz@10 kHz
  • Analysis Bandwidth: Up to 100 MHz
  • 1000M/100M Ethernet Interface
  • Highly Compatible API Interface
  • Linux and Windows Operating Systems Are Supported



Benefits Highlight

NXM-60 is a compact and powerful real-time spectrum analyzer/receiver. It covers a frequency range from 9 kHz to 6.3 GHz, making it suitable for various RF analysis tasks. With features like a 100 MHz analysis bandwidth, fast sweep speed, and an integrated signal generator (optional), the NXM-60 delivers reliable performance in both lab and field environments. NXM-60 extends RF boundaries with its advanced features, making it an excellent choice for spectrum analysis, wireless communication, and research applications.

Get Quote
Categories: ,
Description

KEY FACTS

  • Frequency Range: 9 kHz To 6.3/8.5 GHz
  • 1 GHz DANL: -166 dBm/Hz
  • 1 GHz Phase Noise: -110 dBc/Hz@10 kHz
  • Analysis Bandwidth: Up to 100 MHz
  • 1000M/100M Ethernet Interface
  • Highly Compatible API Interface
  • Linux and Windows Operating Systems Are Supported



Benefits Highlight

NXM-60 is a compact and powerful real-time spectrum analyzer/receiver. It covers a frequency range from 9 kHz to 6.3 GHz, making it suitable for various RF analysis tasks. With features like a 100 MHz analysis bandwidth, fast sweep speed, and an integrated signal generator (optional), the NXM-60 delivers reliable performance in both lab and field environments. NXM-60 extends RF boundaries with its advanced features, making it an excellent choice for spectrum analysis, wireless communication, and research applications.
