NXE Series
KEY FACTS
- Frequency Range: 9 kHz To 9.5/20 GHz
- 1 GHz DANL: -168 dBm/Hz
- 1 GHz Phase Noise: -100 dBc/Hz@10 kHz
- Analysis Bandwidth: Up to 100 MHz
- 1000M/100M Ethernet Interface
- Highly Compatible API Interface
- ARM and X86 Processor Are Supported
- Linux and Windows Operating Systems Are Supported
Benefits Highlight
NXE series excels in network node real-time spectrum analysis, covering 9 kHz up to 20 GHz with a dynamic 100 MHz analysis bandwidth. Its superheterodyne digital receiver and high sweep speed of 300 GHz/s ensure rapid, accurate signal detection. With robust image suppression and IF rejection, the NXE series delivers precise and efficient spectrum analysis. Its compatibility with Ethernet and GNSS, makes it an indispensable tool for professionals seeking reliable and versatile performance.
NXM Series
KEY FACTS
- Frequency Range: 9 kHz To 6.3/8.5 GHz
- 1 GHz DANL: -166 dBm/Hz
- 1 GHz Phase Noise: -110 dBc/Hz@10 kHz
- Analysis Bandwidth: Up to 100 MHz
- 1000M/100M Ethernet Interface
- Highly Compatible API Interface
- Linux and Windows Operating Systems Are Supported
Benefits Highlight
NXM-60 is a compact and powerful real-time spectrum analyzer/receiver. It covers a frequency range from 9 kHz to 6.3 GHz, making it suitable for various RF analysis tasks. With features like a 100 MHz analysis bandwidth, fast sweep speed, and an integrated signal generator (optional), the NXM-60 delivers reliable performance in both lab and field environments. NXM-60 extends RF boundaries with its advanced features, making it an excellent choice for spectrum analysis, wireless communication, and research applications.
NXN Series
KEY FACTS
- Frequency Range: 9 kHz To 4.5/6.3 GHz
- 1 GHz DANL: -162 dBm/Hz
- 1 GHz Phase Noise: -110 dBc/Hz@10 kHz
- Analysis Bandwidth: Up to 25 MHz
- 1000M/100M Ethernet Interface
- Highly Compatible API Interface
- Linux and Windows Operating Systems Are Aupported
Benefits Highlight
NXN series is a versatile and precise tool for real-time spectrum analysis, covering 9 kHz up to 6.3 GHz. It boasts a 6.25 MHz analysis bandwidth and swift 69 GHz/s sweep speed. With a dynamic range of -160 dBm/Hz and robust phase noise performance at -110 dBc/Hz, it ensures accurate and reliable measurements. Ideal for various demanding applications, its compact size and GNSS support make it a dependable choice for professionals on the go.
NXN-400 Series
KEY FACTS
- Frequency Range: 9 kHz To 40 GHz
- 1 GHz DANL: -161 dBm/Hz
- 1 GHz Phase Noise: -107 dBc/Hz@10 kHz
- Analysis Bandwidth: Up to 100 MHz
- 1000M/100M Ethernet Interface
- Highly Compatible API Interface
- Linux and Windows Operating Systems Are Supported
Benefits Highlight
NXN-400 series is a powerhouse for network node spectrum analysis, covering 9 kHz to 40 GHz. Its 100 MHz analysis bandwidth and rapid 300 GHz/s sweep speed ensure swift, reliable signal detection. Enhanced by robust image suppression and IF rejection, the NXN-400 excels in demanding environments. Compact and efficient, it supports Ethernet and GNSS, making it a versatile choice for remote RF spectrum analysis.
Pmax Series Multifunctional Videoscope
| Model | Pmax |
|---|---|
| Probe Diameter(mm) | Φ6.0mm |
| Camera Pixels | 1 mega pixels / 2 mega pixels |
| Image Resolution | 720P / 1080P |
| Video Resolution | 720P / 1080P |
| DOF | 10mm-100mm |
| FOV | 90° / 120° |
| Viewing Direction | front view / side view |
| Light Source | front high bright ceramic light source / rear fibe |
| Brightness Levels | 0-5 level cyclic adjustment |
| Tube Length | 1.5m /3.0m（customized for other length） |
PXE Z Edition
KEY FACTS
- Windows11 operating system
- 1.2 kg lightweight, 8.8-inch multi touchscreen
- Frequency range: 9 kHz to 9.5/20 GHz
- 1 GHz DANL: -168 dBm/Hz
- 1 GHz phase noise: -100 dBc/Hz@10 kHz
- Analysis bandwidth: up to 100 MHz
- CPU: high performance AMD Z1 Extreme
- 16 GB RAM and 512 GB SSD
Benefits Highlight
HAROGIC PXN-400Z handheld spectrum analyzer is up to 40 GHz with 100 MHz bandwidth. It is the latest spectrum analyzer based on Windows 11 operating system and AMD Z1 extreme CPU for effective field computing analysis.
PXE-200 Series
- Frequency Range: 9 kHz to 20 GHz
- 1 GHz DNAL: -165 dBm/Hz (typ.)
- 1 GHz Phase Noise: -101 dBc/Hz@10 kHz (typ.)
- Analysis Bandwidth: 100 MHz
- 3 Hours Battery Time (typ.)
- Channel Power, ACPR, OBM, Phase Noise and More (std.)
Benefits Highlight
PXE series is the real-time spectrum analyzer up to 20 GHz with analytical bandwidth of 100 MHz and ultra-fast speed of 900 GHz/s, delivering standard spectrum sweep (SWP), IQ streaming (IQS), zero span (DET) and real-time analysis (RTA) working mode. The PXE-200 achieves good dynamic range and phase noise level. It can provide customers with spectrum analyzer, spectrum monitoring, interference finding, RF test and measurement functions.
